Health Note Chatbot UX Pattern Library

COLORS

White: #FFFFFF Primarily used as background color and for button text

Cultured: #F3F2F2 Chatbot background color

Platinum: #ECECEC Message bubble, progress bar, and page background color

Light Gray: #D4D4D4 Cancel button background color

Chrome Yellow: #FFA900 Indicator arrow color color

Yellow Orange: #fa9500 Orange Button background color and general indicator color

Fulvous: #D17F05 Text shadow color on Orange Buttons, needed to meet accesibility standards AA of white text on orange buttons

Light Sea Green: #2BB9AE Progress bar color, checked item background color and image loading background

Fadded Persian Green: rgba(23, 161, 150, 0.85) Edit button's background from previous question

Persian Green: #17A196 Green Button background color and signature question green elements

Dark Cyan: #15948A Text shadow color on Green Buttons

Bright Navy Blue: #007AE6 Question link color and input field caret color

Vermilion: #EB0000 Alert text & icons

Fadded Black: rgba(0, 0, 0, 0.45) Answer deactivated button's background from previous question and the multi-select check box outline

Sonic Silver: #767676 Placeholder text color, border color of signature, and color for / on height question and blood preasure question

Dim Grey: #696969 Border color of input fields

Eerie Black: #212121 Question subtext color, cancel button text color and photo instruction background color

Black: #000000 Question text color

TYPE

.percent - Arial(400) 40px #FFFFFF Image upload percentage font

.scroll-notification - Arial(700) 29px (screen width 425px or less font-size = 24px) #FFFFFF Text style used for the Scroll Down footer banner

.info-card-content h3 - Arial(700) 27px #212121

Font for the total amount owed in the payment summary question

.option-text - Arial(400) 25px #212121 Font used for medication names in medication summary

.question-text - Arial(700) 24px #000000 Primary font used in the chatbot question text

.signature .question-text - Arial(700) 24px #17A196 Instruction text used below the signature box

.subtext, .msg_subtext - Arial(400) 24px #212121 Secondary font for the chatbot question text and replicated for use on the credit card payment confirmation answer

.subtext a, .msg_subtext a, .question-text a - Arial(400) 24px #007AE6 Link style for the question text (color applied to .question-text a is still font-weight 700)

.module_meds_eng .list-yes-no .option-text .subtext - Arial(400) 22px #212121 Font used for the medication description summary

input, .text-input, .date-input, .number-input - Arial(400) 23px #000000 Input field font

input::placeholder - Arial(400) 23px #767676 Input field placeholder font

.continue-button, .button-ok - Arial(700) 25px #FFFFFF Text style used for the Continue, Next, OK and other yellow buttons

.button - Arial(400) 25px #FFFFFF Text style used for the default green buttons, option-text buttons, edit and the inactive answers

.button-cancel - Arial(400) 25px #212121 Text style used for the cancel, skip and clear grey buttons

.search-nothing-found, .search-keep-typing - Arial(700) 22px #ffffff Text style used for search as you type message prompts

.go-button - Arial(700) 20px #FFFFFF Text style used for the submit button that accompanies the typical text input field

.btn-ok, .btn-cancel, .btn-more - Arial(700) 20px #000000 Text style used for the edit popup buttons and insurance search show more button

.notification-message - Arial(400) 20px #FFFFFF Text style used for warning messages on the credit card form

.search-item - Arial(700) 19px #212121 Text style used for search as you type selections

BUTTONS

Basic Yes No answer button for questions
For each button: ".option-block .button"

Text

Single select answer buttons when more than one
For each button: ".singleselectflex .option"

Text

Single select answer buttons when only one button is shown. Note the button is only suitable for short single words like "Continue" or "Next".
".singleselectflex .option"

Text

Answer(not clickable) label and Edit button of a past question.
Left button(not really a button): ".option-block.answer .button.button-active"
Right button: ".option-block.answer .button.edit-active"

Text

Popup menu button, like used on the edit menu.
Left button: ".confirmation-popup-controls .btn-ok"
Right button: ".confirmation-popup-controls .btn-cancel"

Continue button in deactive and active states. With arrow below(default use when a button is to the side) and from the side(use when no buttons are to the side unless button is too wide for arrow to fit).
".multiselect .arrow-target .continue-button"

Text

".multiselect .arrow-target.arrow-active .continue-button.continue-button-active"

Text

".arrow-target.arrow-active .continue-button.continue-button-active"

Text

Submit/Go button in deactive and active states
".go-button"

Text

".go-button.go-button-active"

Text

Scroll Down footer banner/button
".scroll-notification.scroll-notification-active"

Text

Cancel button for search as you type (full screen version, used in medication search and insurance search)
".button-cancel.autocomplete-cancel-btn"

Text

Item button from search as you type results (with container background from the menu) This is used in both chatbot quesitons and in full screen searches.
".search-block.search-block-active .search-item"

Text

Edit medication button
".v20 .edit-med.button"

Text

Cancel and Ok buttons from medication summary confirmation question
Left button: ".option-block.option-block-confirm .row-buttons .button-cancel"
Right button: ".option-block.option-block-confirm .arrow-target .button-ok"

Text

Existing medication question's Yes and No buttons
Top button: ".module_meds_eng .list-yes-no .yes-no-option.yes"
Bottom button: ".module_meds_eng .list-yes-no .yes-no-option.no"

Text

Top button: ".module_meds_eng .list-yes-no .yes-no-block.status-yes .yes-no-option.yes.yes-no-option-active"
Bottom button: ".module_meds_eng .list-yes-no .yes-no-block.status-yes .yes-no-option.no"

Text

Newly added medication question's Edit and Delete buttons
Top button: ".module_meds_eng .list-yes-no .edit-rmv-option"
Bottom button: ".module_meds_eng .list-yes-no .edit-rmv-option.rmv"

Text

Image upload question Take image and Skip/Cancel buttons
Left button: ".option-block.controls .upload-actions .button"
Right button: ".option-block.controls .upload-actions .button.inactive"

Text

Insurance carrier question alt option style for unsure and more insurances buttons
Top button: ".insurance-module-v2 .option.insurance-unsure"
Bottom button: ".insurance-module-v2 .option.insurance-more"

Text

Legal documents popup close/done button
".legal-popup .legal-popup-footer .btn-done"

Insurance search list show more button
".search-block-active .btn-more"

Text

The first row shows the signature question Clear button with inactive Continue button (top). The next row shows the Clear button with an active Continue button
Left button: ".signature-button .clear-button.clear-button-active"
Right button: ".signature-button .continue-button"

Text

Left button: ".signature-button .clear-button.clear-button-active"
Right button: ".signature-button .continue-button.continue-button-active"

Text

The first row shows the payment form Cancel button and inactive Pay button. The next row shows the Cancel button with an active Pay button.
Left button: ".component-block.creditcard .continue-button.skip-button"
Right button: ".component-block.creditcard .arrow-target .continue-button"

Text

Left button: ".component-block.creditcard .continue-button.skip-button"
Right button: ".component-block.creditcard .arrow-target .continue-button.continue-button-active"

Text

FORM ELEMENTS

Text basic input

Text basic input with arrow-active

Number basic input

Number fraction input set (used for height and blood preassure questions)

Date input

Date invalid or missing input (same style used on all invalid inputs)

Search as you type/autocomplete input

Default checkbox (top: not selected & bottom: selected)

.multiselect .option .option-icon + .option-text

.multiselect .option.option-active .option-icon + .option-text

Signature box and label

.component-block.signature .option-block .signature-block .canvas-signature

Prototype input field with new label while in focus and input invalid with label (requires a label field be added to the builder and all fields will need label text)

.input-container .text-input.input-with-label

.arrow-target.arrow-active .input-container.input-error .text-input.input-with-label

Messaging

Chatbot banner block

Basic Yes/No question block

.question-text

.subtext .subtext a .subtext b

.button

Answered quesiton example

.question-text

.subtext .subtext a .subtext b

.button.button-active

.edit

Edit previously answered quesitons confirmation popup

Single select question block

.question-text

.subtext

.singleselectflex .option

Single select question block with only one choice. Used regularly for confirmation or progress indicators with continue or next buttons

.question-text

.subtext

.singleselectflex .option

Questionnaire info being uploaded, waiting block

.wait .question-text with .wait .subtext .dot below

Questionnaire info being uploaded, waiting block. Alternate version for when chatbot is shown in kiosk

.question-text

Questionnaire completed block

.end .quesiton-text

Date question block, used for DOB, date of injury, etc.

.question-text

.subtext

.continue-button

Basic question with text input response block (Same format can also be used for number use as well but typicaly the input text is centered)

.question-text

.go-button

Fraction format number response question block, used for height and blood pressure

.question-text

.continue-button

Multiselect question block

.question-text .question-text u

.multiselect .option .option-text

.multiselect .option.option-active .option-text

.continue-button

Medications summary question block

.question-text

.subtext b .subtext

.module_meds_eng .list-yes-no .option-text (status="yes")

.module_meds_eng .list-yes-no .option-text .subtext

Text

.module_meds_eng .list-yes-no .option-text (status="unknown")

.module_meds_eng .list-yes-no .option-text .subtext

Text

.continue-button

Medication details question block

.med-name

.med-dosage

.frequency

text

.question-text

.subtext

.singleselectflex .option

Medications confirmation of details question block

.med-name

.med-dosage

.frequency

text

.question-text

.subtext

.button-cancel

.button-ok

Medications summary question block

.module_meds_eng .list-yes-no .option-text

.module_meds_eng .list-yes-no .option-text .subtext

text

.module_meds_eng .list-yes-no .option-text

.module_meds_eng .list-yes-no .option-text .subtext

text

.question-text

.button

Upload an image question block - initial ask

.question-text

.upload-actions .button

.upload-actions .button.inactive

Take Picture

Upload an image question block - loading image

.question-text

.upload .percent

.upload .button.inactive

Take Picture

Upload an image question block - error messages

.question-text

.upload .error-processing

Take or upload picture

.upload .button.inactive

.unsupported-image

Take Picture

Upload an image question block - image uploaded

.question-text

.upload-actions .button

.upload-actions .button.inactive

.continue-button

Take Picture

Upload an image insurance question block - initial ask

.question-text

.insurance .upload-actions .button

.insurance .upload-actions .button.inactive

Take Picture

Upload an image insurance question block - image uploaded

.question-text

.subtext

.insurance .upload-actions .button

.insurance .upload-actions .button.inactive

.continue-button

Take Picture

Insurance carrier question block

.question-text

.subtext

.singleselectflex .option

.insurance-module-v2 .singleselectflex .option.insurance-unsure

.insurance-module-v2 .singleselectflex .option.insurance-more

Autocomplete search popup block (used for insurance search and medication search without .btn-more )

Autocomplete search question block

.question-text

.subtext

.search-item

.go-button

Agree to terms question block

.question-text

.question-block.info-card-content .subtext p .subtext a

.info-card .option-block .button

Signature question block with error message

.question-text

.subtext

.signature-block .question-text

.signature .signature-error

.continue-button

.clear-button

Payment summary question block

.question-text

.question-block.info-card-content .subtext p

.info-card-content h3

.info-card .option-block .button

Credit card form block with error

.question-text

Payment

.skip-button

.continue-button

.notification-message

Credit card form block after successful payment

.question-text

.component-block.creditcard .option-block.answer .button-active .component-block.creditcard .option-block.answer .button-active a

Icons

default provider banner (should be replaced with client banner)

default provider logo (should be replaced with client logo)

CC cards background for CC form

warning icon for input field

warning icon for input field (current alternate version, should be replaced with circle version)

Indicator arrow for prompting user action

lock/secure icon for CC pay button

Background for instruction on insurance card front upload question

Background for instruction on insurance card back upload question

Review of Systems Profile Icons

body.svg

abdominal.svg

vision.svg

ear.svg

breathing.svg

heart.svg

urinary.svg

lymph.svg

skin.svg

hormone.svg

muscle.svg

mental_health.svg

nervous_system.svg

Preperation Instruction Images

remainder_of_mixture_transparent.svg

combo_pizza_pasta_drink_candy_transparent.svg

broccoli_transparent.svg

seeds_nuts_transparent.svg

questionnaire/tomato_transparent.svg

milk_transparent.svg

juice_pulp_transparent.svg

red_purple_liquids_transparent.svg

pizza_transparent.svg

pasta_transparent.svg

meat_transparent.svg

coffee_transparent.svg

chicken_broth_transparent.svg

juice_transparent.svg

bisacodyl_tablets_transparent.svg

pitcher_with_water_and_2_packets_pouring in_transparent.svg

yellow_gatorade_transparent.svg

polyethylene_glycol_transparent.svg

80z_solution_transparent.svg

bisacodyl_tablets_transparent.svg

jug_transparent.svg

iron_pills_transparent.svg

vitamins_supplements_transparent.svg
